Specifications and Details

Choose from the file types below to meet your needs.
Please Note: BIM files coming soon in 2012.

Use of Hufcor's website details are with the understanding they are for planning and bidding purposes only and are not the final documents from which to build or install our products. Hufcor Distributors will provide the final project shop drawings with dimensions and product requirements

Download Specifications and Details

Click on the appropriate model from the list below. You will go to a menu with drop down screens for specifications. To build CAD Details, select options as needed from the drop down screens.

	Specifications		Details
Products	PDF	Editable	CAD	BIM
Operable Partitions
-- Vertical Lift Folding Doors
Summit 640V Vertical Fold specs, STC min. 51			Contact your Distributor
Bi-Fold Hydraulift Door BF 2 specs			Contact your Distributor
-- Paired Panels, Series 632
632, 3" thick, STC 41-51
642, 4" thick, STC 43-54
-- Omni-Directional (Single Panel) Operable Walls
631, 3" thick, STC 41-51
641, 4" thick, STC 43-54
-- Continuously Hinged (Train)
633E (electric), 3" thick, STC 41-51
643E (electric), 4" thick, STC 43-54
633 (manual), 3" thick, STC 41-51
Hufcor Safety System (HufGard™)
-- Fire Rated Operable Partitions
642F Firewall Paired Panels, STC 51-54
641F Firewall Individual Panels, STC 51-54
-- Pocket Doors for Operable Partitions
-- Glass Operable Partitions
Frameless, Single Panels GL1
Frameless, Paired Panels GL2
Timberframed, single Panels GT1
Timberframed, Paired Panels, GT2
Acoustical Glasswall, Single Panels, GA1
Acoustical Glasswall, Paired Panels, GA2
Accordion Doors
Series 1500 & 2000, est. 15 STC
Series 3100, 3500, 3900, 4100, STC 31, 35, 39 & 41
Series 4500 Specs, STC 45
